Ti-Wire-4

Titanium Wire

Quick Overview

In Stock

Titanium wire is one of our main products.It is available in varying diameters,from 0.030" to 0.236".Our superior quality,quick delivery and good price will meet your specific requirements and help you to fulfil your needs.

Compare
SKU: TI003 Category: Tag:

Product Description

Main Grades:
      AWS A5.16
       2007UNS
       NumberAMSASTM B 863C

      ERTi-1R50100AMS4951Grade-10.030.03-0.100.0120.0050.08
      ERTi-2R50120AMS4951Grade-20.030.08-0.160.0150.0080.12
      ERTi-3R50125AMS4951Grade-30.030.13-0.200.0200.0080.16
      ERTi-4R50130AMS4951Grade-40.030.18-0.320.0250.0080.25
      ERTi-5R56402AMS4956Grade-50.050.12-0.200.0300.0150.22Al¡¡5.5-6.75
       V ¡¡3.5-4.5
      ERTi-7R52401N/AGrade-70.030.08-0.160.0150.0080.12Pd 0.12-0.25
      ERTi-9R56320N/AGrade-90.030.08-0.160.0220.0080.25Al¡¡2.5-3.5
       V ¡¡2.0-3.0
      ERTi-12R53401N/AGrade-120.030.08-0.160.0150.0080.15Mo0.2-0.4
       Ni 0.6-0.9
      ERTi-23R56408AMS4956Grade-230.030.03-0.110.0120.0050.20Al¡¡5.5-6.5
       V¡¡3.5-4.5

Available Diameters, Types and Package Forms:

      Size(mm)§¶0.8 §¶1.0 §¶1.2 §¶1.6 §¶2.0 §¶2.4 §¶3.0§¶3.2 §¶4.0 §¶6.0
      Size (inch) 0.030"0.039"0.047"0.062"0.079"0.094"0.118"0.125"0.156"0.236"
      Straight   √√√√√√√
      Spool√√√√
      Coil   √√√√√√√

Mechanical Properties(min.):

      ASTM GradeUTS ksi(Mpa)0.2YS ksi(Mpa)%EL
      Grade-135(240)20(138)20
      Grade-250(345)40(275)18
      Grade-365(450)55(380)18
      Grade-480(550)70(483)15
      Grade-5130(895)120(828)10

Grade-750(345)40(275)18
      Grade-990(620)70(483)15
      Grade-1270(483)50(345)18
      Grade-23115(793)110(759)10

Standards:
 ASTM B863-14
 AWS A5.16

Brief description about some Titanium grades
 Titanium Grade1–4 are unalloyed or CP Titanium while other grades are alloyed or added with special elements.
 · Grade 1. CP Titanium, lowest strength and high ductility.
 · Grade 2. CP Titanium, most commonly used and the best combination of strength, ductility and weldability.
 · Grade 3. CP Titanium, higher strength.
 · Grade 4. CP Titanium, highest strength unalloyed grade.
 · Grade 5. Most common and widely used alloy Grade. Exceedingly high strength and high heat resistance.
 · Grade 7. Superior corrosion resistance in reducing and oxidizing environments.
 · Grade 9. “ Half”  alloy version of grade 5.Very high strength and corrosion resistance.better ductility, formability,and weldability.
 · Grade 12. Better heat resistance than CP Titanium. Applications same as Grade
 · Grade 23. Titanium-6 Aluminum-4 Vanadium ELI (Extra Low Interstitial)
Alloy,it is often used in surgical implant applications, high strength industrial applications or as marine and offshore energy production components.

Our company have been supplied material to the University and Lab below:
1. Johns Hopkins University
2. Callaghan Innovation Lab
3. King Mongkut‘s University of Technology Thonburi
4. Queens' University Belfast
5. Nanyang Technological University
6. The Islamic Azad University
7. UNIVERSITY OF RZESZóW Poland
8. University of Sheffield UK
9. University of California
