Niobium-plate-3

Niobium plate/sheet

Quick Overview

In Stock

  • Product name   Niobium Sheet / Plate
  • Standard            ASTM B393
  • Grade                  RO4200, RO4210
  • Application:  electronics, metallurgy, chemical, hard alloy cutters, aerospace and aviation.
Compare
SKU: NI006 Category: Tag:

Product Description

Niobium: Gleaming in every color.
Niobium is special because this high level of resistance is achieved at a relatively low weight. We use this material to manufacture coin inserts of all colors, corrosion-resistant evaporation boats for use in coating technology, and dimensionally stable crucibles for diamond growth. Thanks to its high level of biocompatibility, niobium is also used as a material for implants. Thanks to its high transition temperature, niobium is the perfect material for superconducting cables and magnets.

Of coins and diamonds. Applications for niobium.

The applications for which our niobium is used are as diverse as the properties of the material itself. We briefly present two of these below: In actual fact, niobium, like all other metals, is gray. However, by applying a passifying oxide layer, we allow our metal to gleam in a beautiful array of colors. But niobium is not just pretty to look at. Like tantalum, it is resistant against many chemicals and can be easily formed even at low temperatures.

Guaranteed purity.

You can rely on our quality. We use only the purest niobium as our input material. This ensures that you benefit from a very high level of material purity.

Permissible variations in spec.



 Thickness (mm)

 Width (mm)

 Length (mm)

Foil

 0.05~0.1

30~150

>=200

 Sheet

 0.1~0.5

30~500

>=200

 Plate

 0.5~15

 50~1000

>=200

Chemical Composition:

Designation

Main Contents

Impurities maximum

Nb

Fe

Si

Ni

W

Mo

Ti

Ta

O

C

H

N

Nb1

Remainder

0.004

0.003

0.002

0.004

0.004

0.002

0.07

0.015

0.004

0.0015

0.002

Nb2

Remainder

0.02

0.02

0.005

0.02

0.02

0.005

0.15

0.03

0.01

0.0015

0.01
